Overview
Ranpak’s AutoFill™ system saves labor, conserves materials, and increases throughput by accurately dispensing sustainable paper void fill and securely taping the box closed. As a highly flexible solution, it can accommodate a wide range of case sizes at high speed and is scalable to optimize as you grow.
The AutoFill™ solution leverages machine vision and packaging automation technology to create eco-friendly packaging on random box sizes. The system’s ability to precisely measure void fill ensures optimal product protection, while better control of consumables reduces waste and costs. Fully automated, the AutoFill™ system streamlines packaging operations, improving efficiency and productivity. With its advanced features, the AutoFill™ system is the ideal choice for businesses looking to optimize their packaging process.
Features
Ranpak’s AutoFill™ Features:
- Precise & consistent: Accurate void measurement and consistent void filling improve product protection while reducing waste and consumables cost
- Labor savings: Minimizes labor cost at EOL: 1-3 FTEs can be saved and resources re-allocated to higher value-add activities
- High throughput: Continuous operation allows filling and closing of up to 9 boxes per minute
- Quality control: Automatic box QA check with options for left or right reject direction
- Automatic sealng: Fully automatic top taping with bottom tape option
- Sustainable materials: Paper void fill is 100% curbside recyclable
- Easy to operate: Easy access for maintenance, user-friendly HMI for troubleshooting, and paper cart for ease of loading
Specifications
Ranpak’s AutoFill™ Specifications:
- Weight: 3820lbs.
- Dimensions: L 29’ 1-1/2” x W 6’ 2-1/2” x H 8’ 4-1/2”
- Box Size:
- Minimum: 8”L x 6”W x 4”H
- Maximum: 30”L x 20”W x 18.5″H (Standard)
- Maximum: 30”L x 30”W x 28.5″H (Optional)
- Maximum Package Weight: 50 pounds
- Interface: Intuitive touch screen
- Conveyor Speed: 90 feet/minute (adjustable)
- Power: 480 Volts Single Phase
- Power Draw: 20 AMPS
- Paper Type: 30 inch 30# Kraft
- Motion Control: Electric servo motors
Maintenance
Shorr Packaging stands behind all the packaging equipment we represent, with a service network that extends throughout the contiguous U.S.
Our packaging automation specialists offer complete support for equipment selection, integration, installation, training, maintenance, 24/7 emergency service and parts procurement.
All of Shorr’s service technicians are factory certified and dedicated to ensuring that your packaging equipment is always operating at peak performance.
